Puppet
Configuration management
... and maybe something more
A brief history
- ssh looping as a configuration tool
- closed source, high cost software from a big vendor
- no central repository for configuration items
- no central oveview of nodes and state
What is puppet?
Facter
gir informasjon om hosten som det kjøres på
ac02gv1j8djwt:britalinux2014 kbo041$ facter
architecture => x86_64
domain => klientdrift.uib.no
facterversion => 1.7.5
fqdn => ac02gv1j8djwt.klientdrift.uib.no
hardwareisa => i386
hardwaremodel => x86_64
hostname => ac02gv1j8djwt
id => kbo041
interfaces => lo0,gif0,stf0,en0,en3,bridge0,p2p0,fw0,en4
ipaddress => 129.177.11.241
ipaddress_en4 => 129.177.11.241
ipaddress_lo0 => 127.0.0.1
is_virtual => false
kernel => Darwin
kernelmajversion => 13.4
kernelrelease => 13.4.0
kernelversion => 13.4.0
macaddress => ec:1a:59:e7:8c:ee
macaddress_bridge0 => ba:8d:12:91:6d:00
macaddress_en0 => b8:8d:12:19:5f:98
macaddress_en3 => b2:00:1d:a6:98:20
macaddress_en4 => ec:1a:59:e7:8c:ee
macaddress_fw0 => ec:1a:59:7b:a0:72
macaddress_p2p0 => 0a:8d:12:19:5f:98
macosx_buildversion => 13F34
macosx_productname => Mac OS X
macosx_productversion => 10.9.5
macosx_productversion_major => 10.9
macosx_productversion_minor => 5
memoryfree => 90.20 MB
memoryfree_mb => 90.20
memorysize => 4.00 GB
memorysize_mb => 4096.00
memorytotal => 4.00 GB
mtu_bridge0 => 1500
mtu_en0 => 1500
mtu_en3 => 1500
mtu_en4 => 1500
mtu_fw0 => 4078
mtu_gif0 => 1280
mtu_lo0 => 16384
mtu_p2p0 => 2304
mtu_stf0 => 1280
netmask => 255.255.255.0
netmask_en4 => 255.255.255.0
netmask_lo0 => 255.0.0.0
network_en4 => 129.177.11.0
network_lo0 => 127.0.0.0
operatingsystem => Darwin
operatingsystemrelease => 13.4.0
osfamily => Darwin
path => /usr/bin:/bin:/usr/sbin:/sbin:/usr/local/bin:/opt/X11/bin:/Applications/Server.app/Contents/ServerRoot/usr/bin:/Applications/Server.app/Contents/ServerRoot/usr/sbin:/usr/local/git/bin:/usr/local/munki:/usr/texbin
processorcount => 4
productname => MacBookAir4,2
ps => ps auxwww
puppetversion => 3.4.2
rubysitedir => /Library/Ruby/Site/2.0.0
rubyversion => 2.0.0
sp_boot_mode => normal_boot
sp_boot_rom_version => MBA41.0077.B11
sp_boot_volume => Macintosh HD
sp_cpu_type => Intel Core i5
sp_current_processor_speed => 1.7 GHz
sp_kernel_version => Darwin 13.4.0
sp_l2_cache_core => 256 KB
sp_l3_cache => 3 MB
sp_local_host_name => ac02gv1j8djwt
sp_machine_model => MacBookAir4,2
sp_machine_name => MacBook Air
sp_number_processors => 2
sp_os_version => OS X 10.9.5 (13F34)
sp_packages => 1
sp_physical_memory => 4 GB
sp_platform_uuid => 48F5055B-B221-5683-8D1B-DF50A6FD8A83
sp_secure_vm => secure_vm_enabled
sp_serial_number => C02GV1J8DJWT
sp_smc_version_system => 1.73f66
sp_uptime => up 21:11:51:30
sp_user_name => Kristian Botnen (kbo041)
sshdsakey => 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
sshfp_dsa => SSHFP 2 1 989e877651472a5980b62d374c8d4fcacc162017
SSHFP 2 2 ff77fa0e26f3e58f869f8f31b7fef88da506ad7e3040965056a6c1f6eaceeb30
sshfp_rsa => SSHFP 1 1 5f890ab17ccd6f4c310899098af0e49992cc9085
SSHFP 1 2 5c56e1f7a351b0dc57de94cf1a888cf7328390c75e6f7188c6a14553b06b74fe
sshrsakey => AAAAB3NzaC1yc2EAAAADAQABAAABAQCx/WajxEquuk/MLhERvqdlqFhZgIOmvU/PwzStBVC2MZLANsGWNIOw9N6BmB728nXCZ/3FeT4GMosbgIcufp4q9KJz1fWx/C5FvMZjZSsHnTvWSOzd5reOpU6JesIRrSUpTgqgBGyd/C9SRE9wKcbW0lLCdNN64390ev2kQ0N5wI7v4kx0VjGfXgAIBxl0StdkDI+1EEfyaPHsaN8xQfvswBf+pzFycrkKcuC4iqOyPz05eNBKRPmWYDoiahWgaMSQfxHzIgoD6woEUaA18N+FCtDByBi4gg0WxjFAUdssIn4QUhtcWf6xHd0wFl3dXFvmUitWt9Jcx+APWaQwZIvr
swapencrypted => true
swapfree => 1.05 GB
swapfree_mb => 1080.00
swapsize => 2.00 GB
swapsize_mb => 2048.00
timezone => CET
uptime => 21 days
uptime_days => 21
uptime_hours => 515
uptime_seconds => 1857062
virtual => physical
Tilgjengelige facts kan variere mellom operativsystemene
$ facter | egrep "sp_os_version|operatingsystemrelease"Hiera
oppslag av (eksterne) data
---
krb5::manage_keytabs: true
keytabs:
default:
principals: [ 'host', 'nfs' ]
classes:
- platform::ubuntu
- apt::unattended_upgrades
- networkmanager
- autofs
- krb5
- apparmor
- libldap
- ntp
- resolvconf
- ufw
- sssd
- auth_client_config
- grub
- locale
- ssh
puppet_env:
production:
puppet_server: client-pm2.puppet.uib.no
apt_sources:
ubuntu-base-prod:
location: http://repo.uib.no/apt/ubuntu-base-prod
include_src: false
architecture: amd64
apt_keys:
repo_uib:
key: 4E3B734C
key_source: http://repo.uib.no/apt/gpg.key
packages:
augeas-lenses: { ensure: installed }
augeas-tools: { ensure: installed }
firefox-locale-nn: { ensure: installed }
git: { ensure: installed }
inorwegian: { ensure: installed }
iotop: { ensure: installed }
ksh: { ensure: installed }
language-pack-nn: { ensure: installed }
myspell-nn: { ensure: installed }
auth_client_config::override_homedir: false
sssd::ldap_tls_cacert: '/etc/ssl/certs/ca-certificates.crt'
ufw_allow:
allow_TCP_from_SIP:
proto: 'tcp'
port: 5060
from: '129.177.15.201'
allow_UDP_from_SIP:
proto: 'udp'
port: 5060
from: '129.177.15.201'
print_manage_config: true
print_manage_configfilename: legacy_cupsd.conf.linux.erb
print_ppd:
pullprintricoh_ps:
ensure: file
source: puppet:///modules/platform/precise/ppds/pullprintricoh_ps.ppd
path: /usr/share/ppd/uib/pullprintricoh_ps.ppd
owner: root
group: root
print_manage_printers:
#We need to remove old queues that is related to Safecom G2
Pullprint_pcl:
ensure: absent
PullprintRicoh_pcl:
ensure: absent
pullprintricoh_ps:
name: pullprintricoh_ps
uri: lpd://pullprint.uib.no/pullprintricoh
location: Ricoh PS on UiB campus
description: PullPrintRicoh on pullprint.uib.no
ppd: /usr/share/ppd/uib/pullprintricoh_ps.ppd
shared: false
enabled: true
duplex: DuplexNoTumble
page_size: A4
color_model: CMYK
options:
ppd_options:
pullprintricoh_ps2:
name: pullprintricoh_ps2
uri: lpd://pullprint2.uib.no/pullprintricoh
location: Ricoh PS on UiB campus
description: PullPrintRicoh on pullprint2.uib.no
ppd: /usr/share/ppd/uib/pullprintricoh_ps.ppd
shared: false
enabled: true
duplex: DuplexNoTumble
page_size: A4
color_model: CMYK
options:
ppd_options:
pklocalauthority:
aptadmins:
ansatt: true
stud: true
dateadmins:
ansatt: true
stud: true
screenadmins:
ansatt: true
stud: true
localeadmins:
ansatt: true
stud: true
networkmanageradmins:
ansatt: true
stud: true
sudoers:
#apt-get for ansatt
ansatt:apt-get:
type: group
priority: 20
runas: ALL
command: [ '/usr/bin/apt-get' ]
#Klientdrift start
ava009:ukl:
type: user
priority: 20
runas: ALL
kristiancb:ukl:
type: user
priority: 20
runas: ALL
#Klientdrift end
#Infrastruktur start
st02221:ita:
type: user
priority: 20
runas: ALL
och061:ita:
type: user
priority: 20
runas: ALL
#Infrastruktur end
#Brita start
irene:brita:
type: user
priority: 20
runas: ALL
olea:brita:
type: user
priority: 20
runas: ALL
#Brita end
#Local users start
brita:local:
type: user
priority: 20
runas: ALL
#Local users end
#PC-vakter start
pcvakt:kill:
type: group
priority: 20
runas: ALL
command: [ '/bin/kill' ]
pcvakt:reboot:
type: group
priority: 20
runas: ALL
command: [ '/sbin/reboot']
#PC-vakter end
ssh_keys:
ava009:
type: ssh-rsa
key: AAAAB3NzaC1yc2EAAAADAQABAAABAQCmrsGC+0KaGyozoY6pQIZySTfsPdR9qg0zUxsIZRC0z4KyG59gnsPhH6HjBOO0MvXi4SiMY2Me0FTbVAL1LXRFSqSKJa0y2nA1l3zuvZhtcDKUXJVp4ir9cTkcuGFrWaMzORPvbv6VI5BpX6y5UY0VBRV3KUsUiU/wD3axEhageTLdfRjdIrcq4RAz5VCkGCnQ3rMv2O4+OSYg7+cIwSaXMnxLPCDj+j/CjbfH7vaguB6lM9+J3upfvw+HVDj/wqqFXFXtgoHbA9/ObJUJwg2fFVeXb7af3EWOLwjiKbifKDE+gCBoVZH9QPc2uYKCn0bM8sgSCa6PK5vi7U15RH+l
ip: localhost,129.177.10.111
kbo041:
type: ssh-rsa
key: AAAAB3NzaC1yc2EAAAADAQABAAABAQCznqb+k9jWMcM5OS7Y5YDxUSJ9J5knPawc/fReL8tibHs/EaKpQDVO0UqMGX1UzOjWxgLlLu6OEAIau1zPOQlWrt7yABawClqqxANz8i9NX0pd8lb/yEY7GzXmZ8viit6bXagHrp+Df3/9NfoP9BJUu2/2mOYZHfLRPuFuLWY0wY4qbLJQeM/f7EBvdJIEN/T6bHD163sQuz4EDC4xwQNe5tBm2bAjXqErSD8wVjP8bz60LsxcMAtCVPC/E9D/RbSMDJgAd/pihDEoIU+c0XPZgh4OjRXZsJDDfWuehfUfjb4RTY3DQeP7vf1lAfxrJ2SQk3DxDoYGPAn7zJ5MSd9/
ip: localhost,129.177.10.11
sudoers::purge_sudoersd: true
Hieradata kan gjelde for:
- alle maskiner
- et utvalg av maskiner
- en enkelt maskin
- ... nøstes ved behov
Puppet binder det hele sammen
Infrastruktur
Puppetmastere
Konfigurasjon er delt i klient og server
Konfiugrasjonsdata er delt i klient og server
- - -
Klient har dev, test og prod puppetmastere
Klient har faktisk to prod puppetmastere
Server har dev, test og prod puppetmastere
- - -
Alle puppetmasterene har rare navn
- - -
Sjekk alltid at du snakker med den puppetmasteren du tror!
$ cat /etc/puppet/puppet.conf | grep serverNodeclassifier / Foreman
Foreman gjør det enkelt å klassifisere nye noder
Klassifiserer v.h.a grupper basert på ou, plattform, role
Konfigurasjon hieradata knyttes til grupper
Rapport fra puppetnodene sendes til Foreman
- - -
klientadmin, klientadmin.test, serveradmin, serveradmin.test
dev og test -puppetmastere rapporterer til klientadmin.test
prod -puppetmastere rapporterer til klientadmin
Sertifikater / PKI
Et sertifikat består av to deler, 1 på klienten og 1 på serveren
Disse to delene må matche, ellers nekter puppet å kjøre
Sertifikatet opprettes første gang ved installasjon / første puppetrun
- - -
Kan skape problemer ved reinstallasjon
Error: Could not request certificate: The certificate retrieved from the master does not match the agent's private key.
Certificate fingerprint: 61:F8:87:9A:AE:1F:90:88:4B:AE:13:CF:37:AA:BA:B9:69:C9:0C:0E:44:2E:64:AC:4B:1F:74:CA:8B:76:5D:FF
To fix this, remove the certificate from both the master and the agent and then start a puppet run, which will automatically regenerate a certficate.
On the master:
puppet cert clean ac02gv1j8djwt.klientdrift.uib.no
On the agent:
rm -f /var/lib/puppet/ssl/certs/ac02gv1j8djwt.klientdrift.uib.no.pem
puppet agent -t
Om du er på en Mac
# /usr/local/bin/uib_puppet_clean.shLitt om puppet
Abstraksjon / Krossplattform
puppet abstraherer vekk forskjeller mellom plattformer
# dpkg --get-selections
account-plugin-aim install
account-plugin-facebook install
account-plugin-flickr install
# pkgutil --pkgs
com.128bittech.FreeFonts
com.acdsystems.acdsee
com.adobe.acrobat.a11.AdbeRdrSecUpd11002
# yum list installed
Loaded plugins: fastestmirror
Loading mirror speeds from cached hostfile
* base: mirrors.coreix.net
* extras: centos.serverspace.co.uk
* updates: mirrors.coreix.net
Installed Packages
ModemManager-glib.x86_64 1.1.0-6.git20130913.el7 @anaconda
Abstraksjon / Krossplattform 2
puppet lar oss bruke en kommando uavhengig plattform
# puppet resource package
package { 'account-plugin-aim':
ensure => '3.8.6-0ubuntu9.1',
}
package { 'account-plugin-facebook':
ensure => '0.11+14.04.20140409.1-0ubuntu1',
}
package { 'account-plugin-flickr':
ensure => '0.11+14.04.20140409.1-0ubuntu1',
}
# puppet resource package
package { 'BSD':
ensure => 'installed',
}
package { 'CFPropertyList':
ensure => ['2.2.0'],
}
package { 'Gutenprint 5':
ensure => 'installed',
}
# puppet resource package
package { 'ModemManager-glib':
ensure => '1.1.0-6.git20130913.el7',
}
package { 'NetworkManager':
ensure => '0.9.9.1-29.git20140326.4dba720.el7_0',
}
package { 'NetworkManager-glib':
ensure => '0.9.9.1-29.git20140326.4dba720.el7_0',
}
Types and Providers
bruker
# puppet resource user
user { 'brita':
ensure => 'present',
comment => 'Brita Localuser,,,',
gid => '256',
home => '/home/brita',
password => '$1$kJO41PQA$39bKCeUaIksNFdgNXuGjF/',
password_max_age => '99999',
password_min_age => '0',
shell => '/bin/bash',
uid => '256',
}
# puppet resource user
user { 'brita':
ensure => 'present',
comment => 'Universitetet i Bergen',
gid => '20',
groups => ['admin'],
home => '/Users/brita',
iterations => '23148',
password => '602c06734bb02a07993b828c4603830ea94e8deeb82aa0d565fa787d0219c7eefc5740918916ad1455291904a82a53a9b643003839c2f7ac2c460d3b47a190bff47143a7666f14ff6a305767ec10f0d1cf8cb9e4a69f6d958ed21b7c1110f68c70ebdd0b61a61a4771ae4e05f3801c7765b45952f20d05ae0e731a23aea8d87d',
salt => 'c9e5e5a30a7fed991431534e450553dd75866bb8367a3c37c21de75124b1944d',
shell => '/bin/bash',
uid => '501',
}
Types and Providers 2
min favoritt, printer
# puppet resource printer
printer { 'pullprintricoh':
ensure => 'present',
accept => 'true',
description => 'Pullprint Ricoh Safecom PCL',
enabled => 'true',
location => 'Ricoh PCL on UIB campus',
uri => 'lpd://pullprint.uib.no/pullprintricoh',
}
# puppet resource printer
printer { 'ALDERAAN_PullPrintRicoh':
ensure => 'present',
accept => 'true',
description => 'ALDERAAN-PullPrintRicoh',
enabled => 'true',
location => 'Universitetet i Bergen',
uri => 'smb://ALDERAAN.klient.uib.no/pullprintricoh',
}
vi kan også legge til / fjerne en ressurs
# puppet resource package nmap ensure=installed
Notice: /Package[nmap]/ensure: ensure changed 'purged' to 'present'
package { 'nmap':
ensure => '6.40-0.2ubuntu1',
}
La oss se på det hele samlet
La oss se litt på Foreman
La oss se litt på Hieradata
SSH Nøkler
Øvingsoppgave
Lag ditt eget nøkkelsett
$ mkdir ~/.ssh
$ chmod 700 ~/.ssh
$ cd ~/.ssh
$ ssh-keygen -t rsa -b 4096
$ cat id_rsa.pub >> authorized_keys
$ chmod 600 *
$ ls -la
Test nøkkelsettet ditt
$ ssh login.uib.no
La oss forhåndsåpne nøkkelsettet
$ ssh-add
$ ssh login.uib.no
$ exit
$ ssh sync.uib.no
Lær mer
$ man ssh-add
Kjekke kommandoer
List ut skrivere
$ lpstat -a
pullprintricoh accepting requests since 2014-10-24T13:14:32 CEST
pullprintricoh_ps accepting requests since 2014-10-24T13:13:43 CEST
pullprintricoh_ps2 accepting requests since 2014-10-24T13:13:43 CEST
Restarte skriversystemet Mac
# launchctl unload /System/Library/LaunchDaemons/org.cups.cupsd.plist
# launchctl load /System/Library/LaunchDaemons/org.cups.cupsd.plist
Restarte skriversystemet Ubuntu
# service cups restart
cups stop/waiting
cups start/running, process 10478
History
# history
358 lpstat -a
359 service cups restart
360 cat /etc/puppet/puppet.conf
361 clear
362 history
Nyttige konfigurasjonsfiler
/etc/puppet/puppet.conf
# cat /etc/puppet/puppet.conf
[main]
logdir=/var/log/puppet
vardir=/var/lib/puppet
ssldir=/var/lib/puppet/ssl
rundir=/var/run/puppet
factpath=$vardir/lib/facter
templatedir=$confdir/templates
ca_server=client-pm1.puppet.uib.no
certname=it010011.klientdrift.uib.no
server=client-pm2.puppet.uib.no
masterport=443
pluginsync=true
[agent]
environment=production
report=true
runinterval=3600
configtimeout=120
splay=true
splaylimit=1800
usecacheonfailure=true
[user]
report=false
reports=log
# cat /etc/puppet/puppet.conf
[main]
logdir=/var/log/puppet
vardir=/var/lib/puppet
ssldir=/var/lib/puppet/ssl
rundir=/var/run/puppet
factpath=$vardir/lib/facter
templatedir=$confdir/templates
ca_server=client-dev.puppet.uib.no
certname=ac02gv1j8djwt.klientdrift.uib.no
server=client-dev.puppet.uib.no
masterport=443
pluginsync=true
[agent]
environment=dev
report=true
runinterval=3600
configtimeout=120
splay=true
splaylimit=1800
usecacheonfailure=true
[user]
report=false
reports=log
/Library/Preferences/ManagedInstalls
# defaults read /Library/Preferences/ManagedInstalls.plist
{
AppleSoftwareUpdatesOnly = 0;
ClientIdentifier = ac02gv1j8djwt;
DaysBetweenNotifications = 7;
InstallAppleSoftwareUpdates = 1;
InstalledApplePackagesChecksum = 8020feba5aaec332c9995f6a7669a8e2ba5afad81f0ada83339b4e428ebf733e;
LastAppleSoftwareUpdateCheck = "2015-01-08 22:03:25 +0000";
LastCheckDate = "2015-01-08 22:02:58 +0000";
LastCheckResult = 0;
LogFile = "/Library/Managed Installs/Logs/ManagedSoftwareUpdate.log";
LogToSyslog = 0;
LoggingLevel = 1;
ManagedInstallDir = "/Library/Managed Installs";
PackageVerificationMode = hash;
SoftwareRepoURL = "https://munki.uib.no/repo";
SoftwareUpdateServerURL = "";
SuppressAutoInstall = 0;
SuppressStopButtonOnInstall = 0;
SuppressUserNotification = 0;
UseClientCertificate = 0;
}
# defaults write /Library/Preferences/ManagedInstalls DaysBetweenNotifications 2
